Customized 2500w Ultrasonic Seamless Welding Machine 20Khz with Special Wider 22mm Welding Surface
Description:
The ultrasonic sewing machine is mainly composed of a 20Khz ultrasonic transducer, a horn (fixed function), a tool head and a dedicated CNC power supply, and a servo motor system is used to drive the roller to work. The ultrasonic sewing machine uses high-frequency vibration to transmit the sound wave to the welding surface of the workpiece by the welding head, and instantly causes the friction of the workpiece molecules to reach the melting point of the plastic, thereby completing the rapid welding of solid materials and completing the welding. When the non-woven material passes between the ultrasonic welding heads, vibration will be generated on the non-woven fabric and heat will be generated rapidly. This heat causes the synthetic fibers of the non-woven fabric to melt and solidify, creating a seam that will not fray or tear, completely replacing traditional hand stitching.
Specifications:
| Item No | QR-S20DL |
| Power | 2500W |
| Generator | Digital generator |
| Frequency | 20KHZ |
| Voltage | 220V or 110V |
| Width of welding wheel | 22mm |
| Matched Transducer | 5020-4D PZT4 |
| Generator size | 400*195*98mm |
Features:
1. The welding time is short, the ultrasonic automatic suture is free of needle thread, which saves the trouble of frequent needle changing. The sewing speed is 5 to 10 times of the quilting of the sewing machine, and the width is customized by the customer;
2. Since the needle is not used, the stitching process is prevented from remaining in the material, and the safety hazard is eliminated, which belongs to a new generation of safety and environmental protection products;
3. There is no broken wire joint with traditional thread stitching, strong bonding force, clear embossing, more stereoscopic relief effect on the surface, and the product is more high-grade and beautiful;
4. After processing, the finished product has no pinholes and no water seepage, which is more waterproof and protective;
5. Using the roller mold, the mold change is easy, and the ever-changing and complicated discontinuous and symmetrical patterns can be stitched, and various flower-shaped patterns can be developed according to customer requirements;
6. The machine has high degree of automatic intelligence. The assembly of infrared automatic edge-to-edge system can automatically correct the materials of each layer, so that the upper and lower materials are always aligned when sewing, the processing loss is low, and the product is more stable and stable.
