| Products Name: | Ultrasonic Sealing And Cutting Part | Frequency: | 20KHZ |
|---|---|---|---|
| Power: | 2500W | Generator: | Digital Drive |
| Width Of Welding Wheel: | 22mm | Matched Transducer: | 5020-4D PZT4 |
| Generator Size: | 400*195*98mm | Application: | Mask Belt Welding |
| Highlight: | Ultrasonic Sewing Machine Continuous Stitching,20Khz Sealing And Cutting Machine,Curved Mask Belt Ultrasonic Sewing Machine |
||
Needing 20Khz Ultra Sealing and Cutting Machine for Custom Curved Mask Belt Machine
Description:
20Khz ultrasonic sealing and cutting equipment is suitable for continuous stitching. It can also cut textiles while welding, and realize the effect of automatic edge sealing. Ultrasonic sealing and cutting equipment is also called ultrasonic seamless stitching equipment. When stitching, energy penetrates the material layer for welding without heat radiation. During the continuous welding process, heat will not be transferred to the product, which protects the heat-sensitive packaging product. effect.
Specifications:
| Item No | QR-S20DL |
| Power | 2500W |
| Generator | Digital generator |
| Frequency | 20KHZ |
| Voltage | 220V or 110V |
| Width of welding wheel | 22mm |
| Matched Transducer | 5020-4D PZT4 |
| Generator size | 400*195*98mm |
Advantages:
1. High stability: When the ultrasonic is seamlessly stitched, the rotation of the welding wheel and the pressure roller is completely synchronized, and there is no difference in speed and angle, which will not cause stretching, twisting or deformation of the cloth, and the precision is extremely high. Thanks to the hot melt effect, no needle thread is required, the product is more waterproof, lighter in weight and easier to fold.
2. Welding and cutting synchronization: Ultrasonic seamless sewing equipment is not only suitable for continuous sewing, but also for cutting textiles while welding, and achieving automatic edge sealing.
3. No heat radiation: When the ultrasonic is sutured, the energy penetrates through the material layer for welding without heat radiation. In the continuous stitching process, heat is not transmitted to the product, which is particularly advantageous for the packaging of the heat sensitive product.
4. Weldable seam control: The cloth is passed between the welding wheel and the pressure roller, and the fabric is welded by ultrasonic wave. The pressure roller can be changed to change the weld size and embossing, which is more flexible and convenient.
5. Wide range of applications: All thermoplastic (softened and softened) fabrics, special tapes and films can be welded using ultrasonic seamless stitching equipment. The rollers are made of hardened steel to extend the service life.
