Hangzhou Qianrong Automation Equipment Co.,Ltd.
focus on ultrasonic application, in good faith to win customers
| Place of Origin: | China |
|---|---|
| Brand Name: | QRsonic |
| Certification: | CE |
| Model Number: | FSSW-3508-Ti |
| Minimum Order Quantity: | 1 Unit |
| Price: | Negotation |
| Packaging Details: | Packed by Carton |
| Delivery Time: | 5 workdays |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1000 unit/month |
| Model: | FSSW-3508-Ti | Name: | 35Khz Ultrasonic Rotary Welding Machine |
|---|---|---|---|
| Frequency: | 35Khz | Power: | 800w |
| Input Voltage: | 220V±10%，50/60Hz | Working Amplitude: | 18-28μm |
| Materials Of Horn: | Titanium Alloy Or Special Steel | Application: | Fabric Cutting, Lace Cutting, Clothing Stitching, Gluing, Bead Inlay |
| Highlight: | 35Khz Ultrasonic Sealing Machine,Rotary Ultrasonic Cutting Machine,Rotary Ultrasonic Sealing Machine |
||
35Khz Ultrasonic Sealing And Cutting Rotary Machine
Description:
Ultrasonic seamless sewing technology is the latest technological achievement in the world for sewing and cutting fabrics. Fansuoneng Company closely follows the latest scientific research achievements abroad and develops the core of ultrasonic seamless sewing machines. This is the core component of the ultrasonic seamless sewing machine, which completely solves the inherent problem of the original ultrasonic longitudinal vibration technology, that is, the movement direction of the ultrasonic welding head is inconsistent with the movement direction of the fabric. The accuracy of ultrasonic fabric sewing has been greatly improved, which makes the widespread application of ultrasonic technology in the field of clothing sewing possible. Ultrasonic seamless sewing has the characteristics of fast welding speed, high strength, beautiful welds, good sealing performance, low energy consumption, and easy operation, which is the development direction of sewing machines.
Parameters:
| Model | FSSW-3508-Ti |
| Name |
35Khz Ultrasonic Rotary Welding Machine
|
| Frequency | 35Khz |
| Power | 800w |
| Input Voltage | 220V±10%,50/60Hz |
| Welding Amplitude | 18-28μm |
| Materials of horn | Titanium Alloy or Special Steel |
| Application | Fabric cutting, lace cutting, clothing stitching, gluing, bead inlay |
Advantage:
1. High stability: When using ultrasonic seamless sewing, the rotation of the welding roller and pressure roller is completely synchronized, with no difference in speed and angle, which will not cause fabric stretching or deformation, and the accuracy is extremely high. Due to the hot melt effect, there is no need for needles and threads, resulting in increased water resistance, lighter weight, and easier folding of the product.
2. Welding and cutting synchronization: Ultrasonic seamless sewing equipment is not only suitable for continuous sewing, but can also cut textiles while welding, achieving automatic edge sealing.
3. Controllable welding: Welding rollers and pressure rollers pull the fabric, and ultrasonic welding of the fabric. Replacing the pressure roller can change the size and embossing of the weld seam, making it more flexible and convenient to use.
4. Widely used: All thermoplastic (softened after heating) fabrics, specialized tapes, and films can be welded using ultrasonic seamless sewing equipment, and the rollers are made of quenched steel to extend their service life.
35Khz Ultrasonic Sealing And Cutting Rotary Machine
