| Place of Origin: | China |
|---|---|
| Brand Name: | QRsonic |
| Certification: | CE |
| Model Number: | QR-F2030A |
| Minimum Order Quantity: | 1 unit |
| Price: | Negotation |
| Packaging Details: | Packed in wooden case |
| Delivery Time: | 15 workdays |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 2000 unit per month |
| Products Name: | Ultrasonic Metal Welder | Frequency: | 20Khz |
|---|---|---|---|
| Power: | 3000W | Max Output Pressure: | 8000N |
| Air Pressure: | 0.05-0.9Mpa | Working Stroke: | 30mm |
| Highlight: | Copper Tube Sealing Tail Machine,Ultrasonic Sealing Tail Machine |
||
Air Conditioning Copper Tube Refrigerator Condenser Tube Pressure Gauge Copper Tube Ultrasonic Sealing Tail Machine 20Kh
Description:
With the upgrading of environmental protection and heat exchange processes, many refrigerants nowadays use flammable and explosive refrigerants. The application of new refrigerants such as R600, R290, and R1234 is no longer suitable for traditional open flame welding. Therefore, ultrasonic sealing tail welding and cutting equipment can handle such problems and quickly weld and seal without generating open flames. This greatly improves production safety for production enterprises, and does not use any auxiliary materials, resulting in a significant reduction in production costs. This device can also be used for explosion-proof refrigerant sealing welding, improving production efficiency. Generally, sealing the tail of a product takes about 1 second, and for ordinary welding, the efficiency is improved by 80%.
Specifications:
| Item No | QR-F2030A |
| Power | 3000W |
| Diameter of Tube | Φ2-12mm |
| Air Pressure | 0.05-0.9MPa |
| Frequency | 20KHZ |
| Voltage | 220V |
| Weight of horn | 26KG |
| Dimension of Horn | 460*220*1000mm |
| Generator Size | 540*380*150mm |
Product Features:
1. The welding diameter of copper aluminum pipes is 0-12mm (0.8661 inches)
2. No need for acetylene, fusion splicer, brass, solder
3. A simple process ends within 1 second
4. The sealing machine can be operated with one hand with the help of a balance crane, which is convenient and simple
5. Changes caused by changes in pressure height mode compensation tube material
6. Low cost investment and mold replacement costs
7. Ultrasonic sealing has high programmability and reliability, and the sealing process is automatically operated
8. Lightweight ergonomic design, long-lasting welding force, integrated system of two shells, and constant welding parameters ensure welding quality
9. Replace the mold without the need for recalibration, reducing downtime and production costs
