| Place of Origin: | China |
|---|---|
| Brand Name: | QRsonic |
| Certification: | CE |
| Model Number: | QR-2528-4FZ-BT |
| Minimum Order Quantity: | 1 pcs |
| Price: | Negotation |
| Packaging Details: | Packed in carton |
| Delivery Time: | 3 workdays |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 2000pcs per month |
| Products Name: | Ultrasonic Oscillator | Output Power: | 800w |
|---|---|---|---|
| Frequency: | 28khz | Ceramic Disc Diameter: | 25mm |
| Qty Of Ceramic Discs: | 4pcs | Capacitance: | 3900-4300pf |
| Connected Screw: | M8*1 | Application: | Ultrasonic Tea Bag Spot Welder |
| Highlight: | 28Khz Ultrasonic Soldering Transducer,High Frequency Ultrasonic Oscillator,4pcs Ceramics Ultrasonic Oscillator |
||
High Frequency 28Khz Ultrasonic Soldering Transducer with 4pcs Ceramics Welding Horn 8mm Tip
Description:
28K ultrasonic spot welding system is specially designed to weld the movement of tea bag machines, especially for the welding of triangular tea bags. Ultrasonic spot welding gun adopts ultrasonic plastic welding technology.
Due to different processing methods and requirements, the working modes of ultrasonic transducers can be roughly divided into continuous work (metal welding) and pulsed work (plastic welding). Different working modes have different requirements for the transducer. Generally speaking, continuous operation has almost no pause time, but the working current is not very large. Pulse operation is intermittent, with pauses, but the instantaneous current is large, and the power in both states is very large.
Specifications:
| Model | QR-2528-4FZ-BT |
| Frequency | 28 khz |
| Output power | 1200 watt |
| Joint bolt | M18*1 |
| Ceramic disc Diameter | 25mm |
| Qty of ceramic discs | 4pcs |
| Capacitance | 3.9-4.3nf |
| Application | Tea Bag Spot Welder |
Parameters:
|
Item No.
|
Connect screw (Size)
|
Ceramic diameter (mm)
|
Quantity of Ceramic (pc)
|
Resonance frequency (khz)
|
Capacitance |
Input power (W)
|
||
| Yellow | Grey | Black | ||||||
| 1-6015-4BZ-BZ | M16 *1 | 60 | 4 | 15 | 9000-10000 | 10000-11000 | 12500-13500 | 2600 |
| 2-6015-4BZ-LR | M16 *1 | 60 | 4 | 15 | 9000-10000 | 10000-11000 | 12500-13500 | 2600 |
| 3-6015-4BZ-RS | M16 *1 | 60 | 4 | 15 | 9000-10000 | 10000-11000 | 12500-13500 | 2600 |
| 4-7015-4BZ-BZ | M16 *1 | 70 | 4 | 15 | 12500-14000 | / | / | 3600 |
| 5-6015-4BD-BZ | M16 *1 | 60 | 4 | 15 | 9000-10000 | 10000-11000 | / | 2600 |
| 6-6015-6BD-BZ | M16 *1 | 60 | 6 | 15 | 19000-20500 | / | 23000-25000 | 3600 |
| 7-7015-4BD-BZ | M16 *1 | 70 | 4 | 15 | 12500-14000 | / | / | 3600 |
| 8-6015-4BZ-LS | M16 *1 | 60 | 8 | 15 | 18000-20000 | 20000-22000 | / | 4200 |
| 9-4515-4YZ-SS | M16 *1 | 45 | 8 | 15 | / | / | 25000-27000 | 2400 |
| 10-4515-4JZ-SS | M16 *1 | 45 | 8 | 15 | 19000-21000 | / | / | 2800 |
| 11-5015-4BZ-SZ | M16 *1 | 50 | 8 | 15 | 22000-24000 | / | / | 3600 |
| 12-5020-4CZ-BJ | 3/8-24UNF | 50 | 4 | 20 | 11000-12000 | 13000-14000 | 14500-16000 | 1500 |
| 13-5020-4BZ-BJ | 3/8-24UNF | 50 | 4 | 20 | 11000-12000 | 13000-14000 | 14500-16000 | 1500 |
| 14-5520-4BZ-BJ | 3/8-24UNF | 55 | 4 | 20 | 10500-11500 | / | / | 1800 |
| 15-5020-4BZ-BZ | 3/8-24UNF | 50 | 4 | 20 | 11000-12000 | 13000-14000 | 14500-16000 | 1500 |
| 16-5020-4HZ-BJ | 3/8-24UNF | 50 | 4 | 20 | / | / | 11000-12000 | 1500 |
| 17-3820-4BZ-SS | 3/8-24UNF | 38 | 8 | 20 | 13000-14500 | / | / | 1800 |
| 18-5020-4BZ-LS | 1/2-20UNF | 50 | 8 | 20 | 23000-25000 | 26000-28000 | / | 2800 |
| 19-3028-2BZ-BT | / | 30 | 2 | 28 | 2800-3300 | 3300-3800 | / | 400 |
| 20-3828-4BZ-BJ | M8*1 | 38 | 4 | 28 | 7200-8200 | / | 10000-12000 | 800 |
| 21-3828-4BZ-BJL | M8*1 | 38 | 4 | 28 | 7200-8200 | / | 10000-12000 | 800 |
| 22-3828-2BZ-BJL | M8*1 | 38 | 2 | 28 | 3700-4200 | / | / | 500 |
| 23-3030-4BZ-SJL | M10 | 30 | 4 | 30 | / | 6200-7200 | / | 700 |
| 24-3030-4BZ-LJL | M10 | 30 | 4 | 30 | / | 6200-7200 | / | 700 |
| 25-3030-4BZ-BJ | M8 | 30 | 4 | 30 | / | 6200-7200 | / | 700 |
| 26-3535-4BD-II | M8 | 35 | 4 | 35 | 6600-7400 | / | 9200-10200 | 800 |
| 27-3035-4BZ-BJL | M8 | 30 | 4 | 35 | 5500-6200 | / | / | 700 |
| 28-3040-4BZ-BJ | M8 | 30 | 4 | 40 | 5100-5800 | / | 6500-7500 | 500 |
| 29-1560-2BZ-BJ | / | 15 | 2 | 60 | / | / | 700-850 | 100 |
| 30-1070-2BZ-BJ | / | 10 | 2 | 70 | 700-800 | / | / | 100 |
High Frequency 28Khz Ultrasonic Soldering Transducer with 4pcs Ceramics Welding Horn 8mm Tip
