Hangzhou Qianrong Automation Equipment Co.,Ltd.
focus on ultrasonic application, in good faith to win customers
| Place of Origin: | China |
|---|---|
| Brand Name: | QRsonic |
| Certification: | CE |
| Model Number: | QR-3028-2FZ |
| Minimum Order Quantity: | 1 pcs |
| Price: | Negotation |
| Packaging Details: | Packed in carton |
| Delivery Time: | 3 workdays |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 2000pcs per month |
| Products Name: | Ultrasonic Welding Transducer | Frequency: | 28 Khz |
|---|---|---|---|
| Output Power: | 400 Watt | Joint Bolt: | 3/8-24UNF |
| Ceramic Disc Diameter: | 30mm | Qty Of Ceramic Discs: | 2pcs |
| Capacitance: | 2.8-3.8nf | Amplitude: | 8um |
| Highlight: | piezoelectric transducer ultrasound,high frequency ultrasonic transducer |
||
2PCS Ceramics for 28Khz 400w Ultrasonic Weding Tranducer for Mobile Welding
Description:
ultrasonic transducer is an energy conversion device whose function is to convert the input electrical power into mechanical power (ie, ultrasonic waves) and then pass it out, while it consumes a small amount of power (less than 10%). Therefore, the most important consideration for using ultrasonic transducers is the matching with the input and output terminals, followed by the mechanical mounting and mating dimensions. There are many types of ultrasonic machinery on the market, and customers must provide accurate and reliable indicators to ensure that the ultrasonic transducer products provided by the company can be matched with your company's ultrasonic machines to achieve the best performance.
Specifications:
| Model | QR-3028-2FZ |
| Frequency | 28khz |
| Output power | 400 watt |
| Joint bolt | 3/8-24UNF |
| Ceramic disc Diameter | 30mm |
| Qty of ceramic discs | 2pcs |
| Capacitance | 2.8-3.8nf |
| Amplitude | 8 um |
| Application | Plastic welding machine |
Common Questions about ultrasonic transducers:
1. The ultrasonic vibrator is damp. You can check the plug connected to the transducer with a megger. Check the insulation resistance value to judge the basic situation. Generally, the insulation resistance is greater than 5 megohms. If the insulation resistance value is not reached, the transducer is generally damp. The whole transducer (excluding the sprayed plastic case) can be placed in the oven for about 3 hours at 100 °C or used to remove moisture to the resistance value. Normal until now.
2, the transducer vibrator is fired, the ceramic material is broken, and it can be combined with the naked eye and the megohmmeter. Generally, as an emergency treatment measure, the individual damaged vibrator can be disconnected without affecting the normal use of other vibrators.
3, vibrator degumming, our transducer is made of cement, screw fastening double guarantee process, under normal circumstances.
4, stainless steel vibrating surface perforation, the general transducer can be used for 10 years at full load, the vibrating surface perforation may occur.
2PCS Ceramics for 28Khz 400w Ultrasonic Weding Tranducer for Mobile Welding
