Hangzhou Qianrong Automation Equipment Co.,Ltd.
focus on ultrasonic application, in good faith to win customers
| Place of Origin: | China |
|---|---|
| Brand Name: | QRsonic |
| Certification: | CE |
| Model Number: | QR-G2030A |
| Minimum Order Quantity: | 1 unit |
| Price: | Negotation |
| Packaging Details: | Packed in wooden case |
| Delivery Time: | 15 workdays |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 2000 unit per month |
| Products Name: | Ultrasonic Metal Welding | Frequency: | 20KHZ |
|---|---|---|---|
| Power: | 3000W | Voltage: | 380V |
| Welding Speed: | 2-15m/min | Dimension Of Generator: | 540*380*150mm |
| Highlight: | ultrasonic metal welding equipment,ultrasonic welding machine |
||
High Power Ultrasonic Solar Heat Absorbing Plate Core Roll Welding Machine
Description:
Ultrasonic metal roll welding machine is also named ultrasonic copper sheet aluminum sheet copper tube aluminum tube roll welding machine, ultrasonic solar collector plate roll welding machine, ultrasonic solar fin metal rolling machine, ultrasonic solar heat absorbing plate core roll welding machine, whole board Solar collector plate welding machine, flat solar collector welding machine, etc.
Principle:
In the case of pressurization, high-frequency vibration waves are transmitted to the two metal surfaces to be welded by ultrasonic metal welding. The two metal surfaces are rubbed together to form a fusion between the molecular layers, which has the advantages of rapidity, energy saving, high fusion strength, good electrical conductivity, no spark, and near cold processing; the disadvantage is that the welded metal parts cannot be too thick, generally Less than or equal to 5mm, the solder joints should not be too large and require pressurization.
Specifications:
| Item No | QR-G2030A |
| Power | 3000W |
| Air Pressure | 0.05-0.9MPa |
| Frequency | 20KHZ |
| Voltage | 380V |
| Dimension of device | Customized |
| Dimension of Generator | 540*380*150mm |
| Working Mode | Continuous |
| Welding Speed | 2-15m/min |
Features:
- Full servo control system for accurate positioning
- Welding system available in high end and standard configuration
- The equipment is fully automatic and available for selection
- The entire welding process can be completed by simply feeding and touch screen operation, and the operation is simple and quick.
- The overall frame is stable and has a long life
Ultrasonic metal welding machine amplitude parameters:
Equivalent to the temperature of the soldering iron, the amplitude is a key parameter for the material to be soldered. When the temperature is too low, the welding will not be possible. If the temperature is too high, the raw material will be burnt or the structure will be destroyed and the strength will be deteriorated. Because each company chooses a different transducer, the amplitude of the transducer output is different. After adapting the different ratios of the horn and the horn, the working amplitude of the horn can be corrected to meet the requirements. Variable amplitude, functional amplitude, stepwise amplitude variation, etc. have a great influence on the ratio, and the front-to-back area ratio is proportional to the total ratio.
